| Outdoor unit packing (W*D*H) |
818mmx325mmx520mm
|
| Outdoor unit weight ( Net/Gross ) |
23kg/26kg(with pipe)
|
| Outdoor noise level | 50dB(A) |
| Outdoor unit dimension (W*D*H) |
715mmx240mmx492mm
|
| outline dimension (W*D*H) |
770mm×290mm×498mm
|
| Outdoor air flow | 1700m3/h |
| Model | TAC-12CSA/XA61 |
| Indoor air flow (Hi/Mi/Lo) | 500m3/h |
| Indoor unit weight (Net/Gross) | 8kg/11kg |
| Indoor unit packing (W*D*H) |
848mm×318mm×277mm
|
| Indoor noise level (Hi/Mi/Lo) | 38dB(A) |
| Indoor unit dimension(W*D*H) |
777mm×250mm×205mm
|
| Cooling rated current (A) | 4.8(1.3~5.5) |
| Max. current (A) | 5.5 |
| Cooling (W/W) | 3.08 |
| Power supply (Ph-V-Hz) |
1Ph, 220-240V～, 50Hz
|
| Moisture Removal (L/h) | 1 |
| Cooling Capacity (Btu/h) |
12000(3410~13650)
|
| Heating Capacity (W) |
3235(1000~4000)
|
| Max. input consumption (W) | 1260 |
| Cooling Input (W) | 1070(290~1260) |
| Cooling Capacity (W) |
3300(1000~4000)
|
Smart Air Flow
An innovative air conditioning system ensures cool air is directed upwards for a wide-reaching,'shower-style' refreshment. Warm air is blown downwards to deliver a more immersive ‘blanket-style’ air flow. Air is distributed more evenly, avoiding hot, stuffy, or extreme cold distribution.
AI Inverter Algorithm
Proprietary TCL technology reaches the set temperature more quickly, and energy efficiently . The wind is adjusted to ensure perfect performance at the set temperature. Enjoy aircon that’s quicker, more proactive, and energy efficient.
Faster Cooling
A high frequency compressor ensures more rapid comfort – air is delivered down to 18℃ within just 30 seconds, or up to 40℃ within just 60 seconds. Turn on, tailor your temperature, and enjoy quicker refreshment.
Extreme Performance in Extreme Climates
Innovative engineering ensures a premium, extreme weather build. Enjoy no cooling capacity decline in 50℃ temperatures, and non-stop performance in 60℃ temperatures. For an oasis of cool in the harshest of environments.
Self-diagnosis
When encountering any irregularities, the air conditioner will provide feedback information on the display – for immediate diagnosis and simple upkeep.
Safety First Design
A safety-centric build, complete with a fireproof control box provide long-term, peace of mind performance.
I Feel
iFeel mode enables environmental temperature to be taken directly via a sensor built into the remote. Relax in more comfort, with high precision in-room readings and air delivery.
Eco Mode
Hit Eco Mode for a fixed, efficiency optimized 26℃ program. Designed to be kinder on the environment, saving on electricity bills, and maintaining a tight temperature range. Ideal for responsible, fuss-free background performance.
Sleep Mode
Once activated, Sleep Mode will run at lower capacity; maintaining a narrow temperature buffer. Temperature slowly fluctuates during long-term operation, for refreshment tailored to sleep duration – for energy-efficient performance through the night.
Mute Mode
Hit Mute for a hushed, XX dB operation. Non-intrusive performance, lower than a standard laptop hum ensures you can concentrate on the important things.
Power Cut Auto Restart
TCL’s software ensures current air-con settings are memorized. In the event of sudden power loss, the aircon routine will resume as intended once power is re-established.
5 Speed Refreshment
Select from a 1-5 wind level intensity. Broader settings than standard competitors enables you to set a perfect, tightly-tailored air speed.
Control On-The-Go
TCL Home App connectivity enables pre-setting room temperature and on/off timers; for total control while on the move. Return home in superior comfort, or turn off remotely.
Copper Tube
Air conditioning with copper tube is more durability and better cooling efficiency.
